Hybrid Solar Home Energy Storage System
2.5kWh-20kWh 48V 52Ah Off-Grid Appliance
High Voltage Stackable LFP Battery
Inquiry
Overview
Rated Capacity
5kwh 10kWh 15kwh 20kwh
Nominal Voltage
51.2V
Working Voltage
44V-58.4V
Nominal Discharge Current
100A 200A 300A 400A
Nominal Charging Current
50A 100A 150A 200A
Cycle Life
6000 cycles (@80% DoD)
Communication Protocol
CAN/RS485/RS232 (WIFI optional)
Gross/Net Weight (Battery Part)
53.5kg/49kg 107kg/98kg 160.5kg/147kg 214kg/196kg
Battery Rated input Voltage
48Vdc
Hybrid Max. charging Current
80A
Battery Pack Voltage Range
40Vdc-60Vdc
